The Manual Highway Tape Applicator (MHTA-1) is a simple two-wheeled, push-type device for applying 3M™ Stamark ™ and Scotch-Lane™ pavement marking tapes.

The device is specifically designed to apply pavement markings precoated with pressure sensitive adhesive during and immediately following asphalt resurfacing operations. It can also be used to apply pressure sensitive adhesive coated markings on existing surfaces or temporary markings used in construction work zones.

The 160 lb. aluminum and steel applicator can be partially disassembled by removing the handle and pointer, for easy transport.
Also Available in 18” (MHTA-18-2)

Product Width and Spacing
Two 4” (100 mm) lines can be applied at the same time, with 4” (100 mm) spacing between the lines. Combinations of solid and skip lines may be applied simultaneously.

Single lines of widths up to 12” (300 mm) wide can also be installed as a solid line or skip lines. The MHTA can be used to apply all Stamark and Scotch-Lane pavement marking tapes at maximum standard roll lengths.

Note: If special ordering tape, the maximum roll diameter cannot exceed 20” (50.8 cm) if the material is to be applied with a Manual Highway Tape Applicator.

Operation
The tape applicator can be operated by one person. The following application rates are based on asphalt paver speed of 25 – 50 ft./min. and a walking speed of 100 ft./min.
10:30 Skip 750 ft./hr.
15:25 Skip 1125 ft./hr.
Solid Line 1500 ft./hr.
Solid/Skip (NPZ) 2500 ft./hr.
Double Solid 3000 ft./hr.
Overall Average 1000 ft./hr.

Note: The application rates shown are intended as guidelines and may vary with project conditions.
